Anamorphism arises when a grating is used off of the Littrow condition. Specific to spectrographs, anamorphic magnification is a scalar value defined as the ratio of diameters of the major to minor axis in the pupil. Anamorphism is a general property of geometric optical systems with. The anamorphic magnification of ruled-grating spectrographs is a property that must be understood and accounted for when designing ground-based spectrographs. These could be fed by a small network of 1-m telescopes to play an important role in the long-term future of spectroscopic classification of transient events. Our long-term vision is to build not just one R2S2I but multiple. Will revolution time-domain astrophysics with alerts issued on tens-of-seconds timescales. In just a few years a whole slew of facilities including LSST, ASAS-SN, ZTF, TESS, etc. The spectrograph operates at a spectral resolution of 1,000: allowing to to both classify and perform some of the initial science.Īs a result R2S2I will be able to participate in this golden age of rapid-response astronomy. By using a slicer we’ll be able to classify thousands of transients per year down to r~20 on the 40-inch Henrietta Swope Telescope at Las Campanas Observatory.
Echelle grating zemax file plus#
R2S2I uses a wide-field and rapid-readout imager plus a slicer-based integral field unit.
The instrument has been designed as a followup based on lessons learned from both SED Machine (on the Palomar 60 inch) and FLOYDS (on the Las Cumbres Observatory 2 m). The goal of R2S2I is to be the instrument of choice for rapid followup of transient events.
We lovingly call it R2S2I or the “Rapid Response Swope Spectrograph and Imager”. Recently, with the help of postdoc Decker French we have been looking into the design of a new rapid-response spectrograph and imager.
